QSFP High-Speed Differential Cable (8-Pair, 56 Gbps)
Eight-pair differential cable for the short run inside a QSFP module, at 56 Gbps per lane. One series for QSFP28 and QSFP56, rated -40 to +85°C. The purple round jacket is supplied by length for the module builder to terminate. Overall length, leg length, and wire gauge are made to order.
Get a Quote
What is QSFP high-speed differential cable?
Applications
Inside QSFP28 and QSFP56 optical modules, and in switch components where the run from the paddle card to the optical engine is only a few centimeters. The same short differential run shows up in 400G and 800G optics. The cable stays inside the module shell.
Key Benefits
Eight differential pairs keep each lane on its own impedance and hold crosstalk down in a very small space. The outer diameter has to fit the module, so the build stays thin. A shield can be added when pairs sit against each other inside the shell, or left off when the module does not need it. Impedance, skew, and wire gauge are set on the order. A QSFP jumper with plugs on it is quoted separately.
Eight-pair differential cable for the inside of a QSFP module
Purple round cable, eight differential pairs, 56 Gbps per lane. QSFP28 and QSFP56 use this one series, rated -40 to +85°C. Impedance, skew, wire gauge, and whether the pairs are shielded are set on the order.
Product Specifications
| Item | Specification |
|---|---|
| Pairs | 8 |
| Per-Lane Data Rate | 56 Gbps |
| Module | QSFP28 / QSFP56 |
| Operating Temperature | -40 ~ +85°C |
| Jacket Color | Purple; other colors to order |
Key Features
| Feature | Description |
|---|---|
| Construction | Purple round cable, 8 differential pairs |
| Shield | Optional, to order |
| Length | Overall and per leg, to order |
| Wire Gauge | To order |
| Outer Diameter | To order |
| Pair Layout | To order |
Differential cable for the inside of a QSFP module
